Control Characteristics
|
| Control Input Impedance...... |
TTL, low power Schottky, one unit load. (A unit load is 0.8 mA sink current and 40 µA source current.) |
| Control Logic......................... |
Logic “0” (–0.3 to +0.8V) for port ON and logic “1” (+2.0 to +5.0 V) for port OFF. |
|
|
| AVAILABLE OPTIONS |
| 1. Wider Operating Frequency Range |
| 2. Other Type of Connectors |
ENVIRONMENTAL RATINGS
|
| Operating Temperature................. -30°C to +85°C |
|
Storage Temperature..................... -50°C to +120°C
|
| Humidity......................................... |
MIL-STD-202F, Method 103B, Cond. B (96 hrs. at 95%) |
| Shock.............................................. |
MIL-STD-202F, Method 213B, Cond. B (75G, 6 msec) |
| Vibration......................................... |
MIL-STD-202F, Method 204D, Cond. B (.06” double amplitude or 15G, whichever is less) |
| Altitude........................................... |
MIL-STD-202F, Method 105C, Cond. B (50,000 ft.) |
