Switching Time |
ON time........................................... 25 nsec max. |
OFF time......................................... 25 nsec max. |
Switching Rate......................................1 MHz max |
|
|
Power Handling Capability |
Without Performance Degradation...... 100 mW cw or peak |
|
Survival Power...................................... 25°C 1W cw |
|
|
Power Supply Requirements
|
+5V ±2%, 250 mA max
–12V ±2%, 110 mA max |
|
|
Control Characteristics
|
TTL Control, “0” = Insertion Loss, “1” = Isolation |
|
ENVIRONMENTAL RATINGS
|
Operating Temperature Range........................ –54°C to +85°C
|
Non Operating Temperature Range................ –55°C to +125°C
|
Humidity........................................................... MIL-STD-202F, Method 103B, Cond. (96 hrs. at 95%) |
Shock................................................................ MIL-STD-202F, Method 213B, Cond. C (100G/ 6/msec)
|
Vibration........................................................... MIL-STD-202F, Method 204D, Cond. G (30g PEAK) |
Altitude............................................................. MIL-STD-202F, Method 105C, Cond. C (70,000 ft.) |
Temp. Shock..................................................... MIL-STD-202F, Method 107D, Cond. A, (5 cycles) -55°C to +125°C
|
Seal .................................................................. MIL-STD 202F, Method 112C, Cond. C 5x10-7 |
Salt Spray......................................................... MIL-STD 202F, Method 101D+EST., Cond. B |
